Complete sawmill (stationary)

Pilous CTR750LX-5,5

The new, ultra-modern, solid log band saw from Holzprofi is for a log diameter of up to 75 cm and offers many options for cutting your wood and logs correctly. Maximum cutting precision thanks to cutting thickness calculator, lower part galvanized, upper part powder-coated including pre-cutting device! For all types of wood, logs or old wood. Can be extended indefinitely with extension sections. Very stable thanks to solid welded frame. CE tested. The original!, not a replica!!!

Technical data:
max. log diameter 750 mm
max. board width 620 mm
motor output S6 7 kW (5.5 kW S1)
motor output feed motor 0.37 kW
max. feed speed 17 m/min
cutting length 3.45 m (can be extended without limit)
min. cutting length without aids 0.75 m
saw band length 4140 mm
saw band width up to 35 mm
diameter of the band wheels 500 mm
dimensions W x H x L 1980 x 1670 (1910) x 5300 mm
band speed 13 m/sec
weight 460 kg
standard equipment:
- electric feed, continuously adjustable
- electronic speed display
- electric height adjustment with electronic height display
- cutting thickness calculator with automatic travel to the
Bwjdpfx Aovrvigsktow

specified height
- special device for setting the exact wood thickness
- 2 basic sections
- 3 90° angle stops
- 3 log clamping devices
- Band tension indicator
- Bimetal saw blade for all types of wood
- Hydraulic band tension indicator
- Irrigation valve

Optional equipment
- Extension section with angle stop and log clamping device
extends the cutting length per piece by 2.25 m
- 7.5 kW motor
- Cover tarpaulin
- Sharpening machine
- Setting device
- Log turning lever
